Module điều khiển ZETA ZAIO-MI

Module điều khiển ZETA ZAIO-MI
– The ZAIO-MI is both an input and output module in a modern enclosure (2 gang box size) with well protected electronic circuit board to minimize any damages during installation.
– It is supplied with a back box suitable for surface mount indoor installation. Designed and manufactured to meet the requirements of EN54-18 2005 and EN54-17 2005.
Applications
– The ZAIO-MI is used when both an input needs to be monitored and at the same time a local output (relay output) needs to be triggered to switch ancilliary equipment on or off during an alarm condition.
– Typical output triggering includes: controlling lift operation during an alarm, starting fire pump, stopping ventilation fans etc.
– For more details and connection information consult the installation guide.
Special Features
– Loop powered (60 devices per loop as maximum).
– Hand addressed using the 8 way dip switch OR.
– Softly addressed using our handheld MKII Programmer (part no. 48-004).
– Equipped with short circuit line isolator.
– Extensive front unit indications.
Đặc tính kỹ thuật: Module điều khiển ZETA ZAIO-MI

Model

ZAIO-MI

Operating Voltage

17-28V DC

Quiescent Current @ 24V

1.0mA

Switch Input Closed (LED OFF)

1.25mA

Relay Operated (LED ON)

2.0mA (Max 2 LEDs on)

Relay Rating

SELV @ 1A

Isolating Current

7.3mA

Input End Of Line

20k

Alarm Triggering Resistor

1k

Operating Temperature

-10°C to +55°C

Max Humidity

95% RH Non Condensing

IP rating

IP21C

Size (mm)

150 x 90 x 45

Weight

220g
